Casagrand Madelyn

The Casagrand Madelyn by Casagrand Builder Private Limited is a high-rise project located in Chromepet, Chennai, that will give you an upgrade to your life. This luxurious residence has been designed in a way that will allow you to live an elite lifestyle and enjoy your time there; the layout includes both 2 and 3 BHK to allow for more than enough room for you and your family to live comfortably. Each unit ranges from 1673 sq ft to 2059 sq ft to ensure all your family members get plenty of quality time together. There are also over 65+ modern amenities located throughout the property that can enhance your overall standard of living and well-being. One notable amenity brings many residents back to their childhood memories.

As a whole community, there are a total of 6.47 acres, giving each resident access to a full fitness center and equipment to improve physical activity and fitness. The landscaped gardens and outdoor spaces create an aesthetically pleasing view as well as a place for each resident to unwind after a long day. Residents will also have access to an outdoor yoga deck to assist with meditative peace. Casagrand Madelyn in Chrompet is made up of 394 units, so you have the ability to choose the right unit for you. The project has a central location, making all other locations easily accessible for residents.

SPECIFICATIONS

STRUCTURE

Structural System :

• RCC Framed Structure designed for seismic compliant (Zone-III)

Masonry (Conventional) :

• 200mm for external walls & 100mm for internal walls

Floor- Floor height (incl. slab) :

• Will be maintained at 3200mm (Aspiration/Affordable/Superior)

WALL FINISH

Internal walls :

• Finished with 2 coats of putty, 1 coat of primer & 2 coats of premium emulsio

Ceiling :

• Finished with 2 coats of putty, 1 coat of primer & 2 coats of tractor emulsion

Exterior walls :

• Finished with 1 coat of primer & 2 coats of exterior emulsion paint & color as per architect design intent

Bathroom :

• Glazed / Matte ceramic tile of size 300X600mm for a height of 2550mm & above false ceiling will be finished with a coat of primer

Toilet ceiling :

• Grid type false ceiling

FLOOR FINISH WITH SKIRTING

Main flooring :

• Vitrified tiles of size 600X600mm

Bathroom :

• Anti-skid ceramic tiles of size 300X300mm

Balcony :

• Anti-skid ceramic tiles of size 600X600mm

Private open terrace (if applicable) :

• Pressed tiles finish

KITCHEN & DINING

Kitchen :

• Will be left open for modular work with electrical points & plumbing provisions.

Electrical point :

• For chimney & water purifier

Dining :

• Wall hung basin wherever applicable

BALCONY

Handrail :

• MS handrail as per architect’s design intent

BATHROOMS

CP & Sanitary fixture :

• Jaguar or Equivalent

Bed -1 Bathroom :

• Wall mounted WC with cistern, Health faucet, Single lever diverter with overhead shower & Granite counter wash basin and granite ledge

Other Bathroom :

• Wall mounted WC with cistern, Health faucet, Single lever diverter with overhead shower & wall hung wash basin

JOINERY

Doors:

• Main door : Good quality door frame with double side veneer shutter of size 1200X2400mm with polish finish.

• : Ironmongeries like Digital lock system of Yale or equivalent lock, Tower bolts, door viewer & magnetic catcher.

• Bedroom doors : Good quality door frame with Laminate shutter of size 1000X2400mm with paint finish

• : Ironmongeries like lock, door stopper, door bush, tower bolt, etc., of yale/equivalent brand

• Bathroom doors : Good quality door frame with Laminate shutter of size 800X2400mm with paint finish

• Ironmongeries like one side coin thumb turn lock without key, tower bolt , door bush, etc., of yale / equivalent brand

WINDOWS

Windows :

• Powder coated Aluminum windows with sliding shutter with see- through toughened glass and MS grill/railing on the inner side (wherever applicable)

• Sill coping with granite

French doors :

• Powder coated Aluminum frame and doors with toughened glass (wherever applicable)

Ventilators :

• Powder coated Aluminum frame of fixed louver/ open-able shutter for ODU access (wherever applicable)

• Sill coping with Tile

ELECTRICAL POINTS

• Power Supply : 3 PHASE power supply connection

• Safety device : MCB & RCCB (Residual current circuit breaker)

• Switches & sockets : Modular box & modular switches & sockets of good quality IS brand

• Wires : Fire Retardant Low Smoke (FRLS) copper wire of good quality IS brand

• TV : Point in Living & any one bedroom and provision in otherbedrooms

• Data : Point in Living & any one bedroom

• Split- air conditioner : Point in living/Dining & in all bedrooms for 1BHK & 2BHK

• Points in Living & all bedrooms and provision in dining for 3BHK units)

• Exhaust fan : Point in all bathrooms

• Geyser : Point will be given in all bathrooms

• Back-up : 350Watts for 1BHK, 400 Watts for 2Bhk & 500 Watts for 3Bhk

COMMON FEATURES:

• Lift : Automatic lift will be provided with MS Finish

• Back – up : 100% Power backup for common amenities such as Clubhouse, lifts, WTP, STP & common area lighting

• Name board : Apartment owner name will be provided in ground floor

• Lift fascia : Granite cladding at all the floor for threshold of 300mm

• Lobby floor : Granite flooring at ground floor & tile flooring at other floors

• Corridor floor : Tile flooring at all floors

• Staircase floor : Granite flooring for 4 floors & tile flooring at other floors

• Staircase handrail : MS handrail with enamel paint finish in all floors

• Terrace floor : Pressed tile flooring

• Terrace doors : Good quality door frame with FRP shutters of size 900 X 2100mm

• Ironmongeries like thumb turn lock, door closure, tower bolt of yale / equivalent brand

OUTDOOR FEATURES:

• Water storage : Centralized UG sump with WTP (Min. requirement as per water test report)

• Rain water harvest : Rain water harvesting system (as per site requirement)

• STP : Centralized Sewage Treatment plant

• Safety : CCTV surveillance cameras will be provided all round the building at pivotal locations in ground level

• Well defined walkway : Walkway spaces well defined as per landscape design intent

• Security : Security booth will be provided at the entry / exit facilitated with MY GATE App

• Compound wall : Site perimeter fenced by compound wall with entry gates for a height of 1800mm.

• Featured Compound wall (wherever applicable) As per design intent

• Landscape : Suitable landscape at appropriate places in the project as per design intent

• Driveway : Convex mirror for safe turning in driveway in / out

• External Driveway : Interlocking paver block / equivalent flooring with demarcated driveway as landscape design intent

• Granite flooring finish / Cobble stone in entrance driveway and Block lobby entrance

Distance from Schools

• Jain Public School 2 mins

• The Lords' International School 12 mins

• Maharishi Vidya Mandir CBSE School 4 mins

• Mahalakshmi Vidya Mandir CSBE School 10 mins

• Sri Seshadri Matri School 12 mins

• Shanthi Anand Vidyalaya School 2 mins

• Shikshaa public CBSE School 30 mins

• Mukkala Nammalwar Chetty Vivekananda Vidyalaya CBSE School 12 mins

• Srimathi Sundaravalli Memorial CBSE 10 mins

• Sri Krish International School 20 mins

• Arul Jothy Public School 25 mins

• Holy Queen Matri School 15 mins

Distance from Colleges

• Madha Engineering College 5 mins

• Madha Dental College & Hospital 5 mins

• Joseph’s College (Arts & Science) 20 mins

• Madras Institute of Technology, Anna University 15 mins

• Madras Christian College 20 mins

• Sree Balaji Medical College And Hospital 15 mins

• SDNB vaishnav college for Women 25 mins

• Sri Muthukumaran Arts And Science College 20 mins

• Tagore Engineering College 15 mins

Distance from Hospitals

• Sree Balaji Medical College And Hospital 15 mins

• Madha Dental College & Hospital 10 mins

• JIP Multi Speciality Hospital 20 mins

• Rela Hospital - Multispeciality Hospital 15 mins

• Sugam Hospital 15 mins

• Hindu Mission Hospital 20 mins

• Sivam Hospital 6 mins

Distance from Nearby Vicinities

• Pallavaram Junction 15 mins

• Kundrathur 12 mins

• Chromepet 22 mins

• Thiruneermalai 2 mins

• Pammal 15 mins

• SIDCO 2 mins

• Meenambakkam 20 mins

Distance from Airport, Railway Station, Bus Stand & Metro

• Chennai International Airport 20 mins

• Pallavaram Railway station 15 mins

• Chromepet Railway station 15 mins

• Kundrathur Bus stand 10 mins

• Proposed Poonamallee Metro 15 mins

• IT Hubs

• MEPZ 10 mins

• Embassy Tech Zone 20 mins

• DLF IT Park 35 mins

• Gateway Office Park 20 mins

About Casagrand

Established in 2003 and headquartered in Chennai, Casagrand is a leading real estate developer committed to building aspirations and delivering value. With over 160 residential landmarks across major cities like Chennai, Bengaluru, Hyderabad, Coimbatore, and Pune, Casagrand has earned the trust of thousands of families.

The Essence of Casagrand

Diverse Portfolio

Casagrand offers a wide range of properties, including luxury apartments, independent villas, and plotted developments, catering to various market segments.

Commitment to Quality

The company prioritizes quality, timely delivery, and customer satisfaction by constantly innovating and adhering to high standards in construction and design.

Strategic Expansion

Beyond residential development, Casagrand has diversified into commercial and industrial real estate, enhancing its offerings and solidifying its position in the industry.

Vision, Mission & Values

Vision

• To deliver exceptional homes that bring joy and satisfaction to customers, creating an unmatched living experience.

Mission

• To become one of the leading developers in India.

• To be the most preferred company to work for, built on a unique culture.

• To be recognized as one of the most trusted brands in the country.

Purpose

• To serve society by providing quality homes at competitive prices.

• To offer career growth and benefits to employees.

• To delight customers at every step.

Core Values

Belief, Aggressive Growth, Innovation, Fairness, Passion.
